Southeastern Railway Museum

Steam Locomotives


#21

Chattahoochee Valley #21

  • builder:Baldwin Locomotive Works
  • arrangement:2-8-0 Consolidation
  • built:1924, Baldwin #57707
  • fuel:soft coal / water
  • notes:
  • 20" x 26" cylinders, 50" drivers
  • blt Tennessee, Alabama & Georgia #201
    to Chattahoochee Valley, 1935
    to standby service, 1946; retired 1961
    to Southeastern Railway Museum
  • builder
    chv21g4 chv21g1 chv21g2 chv21g3 chv21g5 chv21g6 chv21g7 chv21g8 chv21g9

    Feb 2018 / RWH

    chv21l chv21j chv21k

    Feb 2018 / RWH

    tag_jump

    See also our complete Chattahoochee Valley Railroad scrapbook in Shortlines

    srm_postcard5

    postcard / collection


    #290

    Atlanta & West Point #290

  • builder:Lima Locomotive Works
  • arrangement:4-6-2 "Pacific"
  • class:USRAh P-74
  • built:1926, Lima #7008
  • fuel:soft coal / water
  • notes:
  • 27x28" cylinders, 74" drivers
  • blt Atlanta & West Point #290
    to City of Atlanta
    to Southeastern Railway Museum
    used in New Georgia excursions
    under restoration
  • builder

    HawkinsRails thanks Atlanta NRHS members Freddy Frank and Ray Leader
    for use of their Atlanta & West Point #290 images

    tag_check
    awp290c1 awp290c2 awp290c3 awp290c4 awp290c5 awp290c6 awp290c7 awp290c8

    Freddy Frank / collection

    awp290_flyer1

    1989 excursion flyer / collection

    awp290_flyer2
    awp290_terminal

    AWP #290 at Atlanta Terminal Station - J. Reid - 1987 / collection

    srm_postcard13

    postcard / collection


    #750

    Savannah & Atlanta #750

  • builder:American Locomotive Company
  • arrangement:4-6-2 "Pacific"
  • built:1910, ALCO #46567
  • fuel:soft coal / water
  • notes:
  • blt Florida East Coast #80
    to Savannah & Atlanta #750, 1934
    to Atlanta Chapter NRHS, 1962
    leased by SOU for excursions 1967-84
    to Southeastern Railway Museum
  • builder
    sa750h

    from Georgia Short Line Railroad Album
    / collection

    sa750f sa750g sa750h sa750i sa750j sa750k sa750l sa750m sa750e

    Feb 2018 / RWH

    sa750n1 sa750n2 sa750n3

    Feb 2018 / RWH

    srm_postcard11

    postcard / collection

    srm_postcard12

    postcard / collection

    sa750t2 sa750t3 sa750t1 sa750t4

    Feb 2018 / RWH

    srm_postcard9

    postcard / collection

    srm_postcard7

    postcard / collection

    General II

    General II

  • builder:Baldwin Locomotive Works
  • arrangement:4-4-0 "American"
  • built:Aug 1919, Baldwin #52207
  • fuel:coal / water
  • notes:
  • 60" drivers
  • blt Red River & Gulf #104
    to Louisiana Eastern #1
    (Comite Southern #1)
    to Stone Mountain Scenic, 1961
    (named General II for park use)
    to Southeastern Railway Museum, 2007
  • builder
    tag_jump

    See also our complete Louisiana Eastern steam scrapbook in Shortlines

    srm_postcard10

    postcard / collection

    sms104_clipping2

    from Steam in the Sixties
    - Ron Ziel & George Foster (1967) / collection

    general7 general6

    Duluth, Ga / Nov 2020 / RWH

    srm_postcard4

    postcard / collection

    general8a general8b general8c general8d general8e general8f general8l general8g general8h general8i general8j general8k general8m general8n general8o

    Nov 2020 / RWH

    tag_jump

    See also our complete Stone Mountain Scenic Railroad scrapbook in Preservation

    #9

    Campbell Limestone #9

  • builder:Heisler Locomotive Works
  • arrangement:2 truck, 55 ton
  • built:1923, Heisler #1479
  • fuel:wood / water
  • notes:
  • 15.5" x 14" cylinders, 38" drivers
  • blt Kentucky Lumber Company #9
    to Carolina Tie & Lumber
    to Santee River Hardwood Company
    to Campbell Limestone
    to Vulcan Materials
    to Southeastern Railway Museum
  • builder
    campbell9e1 campbell9e2 campbell9e4 campbell9e3 campbell9e5 campbell9e6 campbell9e7 campbell9e8 campbell9e9

    Nov 2020 / RWH

    icon_wikipedia

    The Heisler locomotive was the last variant of the three major types of geared steam locomotives. Charles L. Heisler received a patent for the design in 1892, following the construction of a prototype in 1891. Somewhat similar to a Climax locomotive, Heisler's design featured two cylinders canted inwards at a 45-degree angle to form a 'V-twin' arrangement. Power then went to a longitudinal drive shaft in the center of the frame that drove the outboard axle on each powered truck through bevel gears in an enclosed gearcase riding on the axle between the truck frames. The inboard axle on each truck was then driven from the outboard one by external side rods. The Heisler was the fastest of the geared steam locomotive designs, and yet was still claimed by its manufacturer to have the same low-speed hauling ability.

    Wikipedia

    campbell9_clipping

    brochure clipping / collection
