New Orleans & Gulf Coast Railway Company

tag_quote

riogrande_logo With a tireless approach to improvement, Rio Grande Pacific continues to streamline its combination of infrastructure, train operation efficiency, and personnel to offer seamless freight capabilities in each short line. At RGPC, we know what it takes to operate within the increasingly complex regulatory and logistical challenges to move freight efficiently. The firm’s operations include four short line railroads operating on some 700 total route miles in six states. RGPC properties serve approximately 140 freight customers, including many Fortune 500 firms, and move a diverse mixture of commodities in the agricultural, chemical, lumber, mineral and recycling industries.

Rio Grande Pacific

nogc_state The New Orleans & Gulf Coast Railway Company operates 32 miles of industrial shortline trackage spread out along the west bank of the Mississippi River, south of New Orleans, Louisiana. The first line begins at an interchange with the Union Pacific at its small Westwego yard, east of the UP's large Avondale classification yard. From the interchange, the line travels east (downriver) through the West Bank communities of Marrero, Harvey, and Gretna to Algiers. Between Gretna and Algiers, a second line branches southeast at Gouldsboro Yard, crossing the Intracoastal Canal then rejoining the west bank of the Mississippi at Belle Chasse. From there this line follows the west bank in Plaquemines Parish through the river communities of Oak Point and Alliance to Myrtle Grove -- 24 miles in total. Railroad offices are in Belle Chasse, but locomotives are often kept near the Harvey Canal at a small yard office. Commodities carried for over 20 customers include food products, oils, grains, petroleum products, chemicals, and steel products. The New Orleans & Gulf Coast is one of four shortlines controlled by the Rio Grande Pacific Corporation.

The Westwego-Algiers line was received from Union Pacific, but is actually an amalgamation of portions of two parallel lines constructed by Union Pacific predecessors and rivals. The line closer to the river was a Texas & Pacific route, built along the river to service the industry-rich areas between Waggaman and Algiers. The T&P was absorbed by the Missouri Pacific in 1976, which in turn was absorbed by the Union Pacific beginning in 1980, completed in 1997. Running parallel to the T&P between the same communities was another route originally built by Morgan's Louisiana & Texas Railroad, which would later become the Texas & New Orleans Railroad, a subsidiary of the Southern Pacific system. When the SP was merged into the Union Pacific, this line, too, came under the control of the UP.

The Gouldsboro-Myrtle Grove line was purchased from previous shortline New Orleans Lower Coast Railroad, which was a RailTex subsidiary. The NOLR purchased the 24 mile segment from the Union Pacific in 1991. The route had been a Missouri Pacific branchline before the UP merger, but was built in 1891 by the New Orleans, Fort Jackson & Grande Isle Railroad. In 1911, this company was combined with the New Orleans Southern Railway to form the New Orleans, Southern & Grand Isle Railway, which by 1916 was sold to form the New Orleans & Lower Coast Railroad. By 1926 this last independent operation was under the control of the Missouri Pacific and later absorbed.

nogc_map

NOGC route map / web

nofjgr_guide1893

1893 Official Guide ad / collection

nos_guide1910

1910 Official Guide ad / collection

sp_banner1910
mlt_banner1910

1910 Official Guide ad / collection

mlt_guide1910

1910 Official Guide ad / collection

tp_logo1910
tp_guide1910

1910 Official Guide ad / collection

tp_banner1910
tp_banner1955
tp_guide1955

1955 Official Guide ad / collection

nolc_guide1955

1955 Official Guide ad / collection

nolc_roster_clipping1973

from Railroad magazine
- Sy Reich - Jul 1973 / collection

nolr_guide1994

1994 Official Guide ad / collection

nola_map

New Orleans area map / RWH

Motive Power

New Orleans & Gulf Coast #1011

  • builder:Electro Motive Division
  • model:GP38-3 (rebuilt)
  • type:B-B road switcher
  • built:Feb 1971, EMD #37192
  • series:1221 produced 1965-71
  • engine:EMD 645E3 (16 cyl, 3000 hp)
  • notes:
  • blt Baltimore & Ohio #3768 (GP40)
    to CSX Transportation #6544
    to Union Pacific #2511
    to Union Pacific #1011 (GP38-3)
    to Helm Leasing #1011
    to New Orleans & Gulf Coast #1011
  • builder

    New Orleans & Gulf Coast #1015

  • builder:Electro Motive Division
  • model:GP38-3 (rebuilt)
  • type:B-B road switcher
  • built:Oct 1966, EMD #32153
  • series:1221 produced 1965-71
  • engine:EMD 645E3 (16 cyl, 3000 hp)
  • notes:
  • blt Richmond Fred Potomac #125 (GP40)
    to CSX Transportation #6859
    to Union Pacific #2515
    to Union Pacific #1015 (GP38-3)
    to Helm Leasing #1015
    to New Orleans & Gulf Coast #1015
  • builder

    New Orleans & Gulf Coast #1021

  • builder:Electro Motive Division
  • model:GP38-3 (rebuilt)
  • type:B-B road switcher
  • built:Nov 1971, EMD #38543
  • series:1221 produced 1965-71
  • engine:EMD 645E3 (16 cyl, 3000 hp)
  • notes:
  • blt Baltimore & Ohio #4063 (GP40)
    to CSX Transportation #6638
    to Union Pacific #2521
    to Union Pacific #1021 (GP38-3)
    to Kansas City Southern #1021
    to Helm Leasing #1021
    to New Orleans & Gulf Coast #1021
  • builder

    New Orleans & Gulf Coast #3875

  • builder:Electro Motive Division
  • model:GP38-3 (rebuilt)
  • type:B-B road switcher
  • built:Mar 1967, EMD #32876
  • series:1221 produced 1965-71
  • engine:EMD 645E3 (16 cyl, 3000 hp)
  • notes:
  • blt Illinois Central #3056
    to Kansas City Southern #?
    to Helm Leasing #3875
    to New Orleans & Gulf Coast #3875
  • builder

    New Orleans & Gulf Coast #3876

  • builder:Electro Motive Division
  • model:GP38-3 (rebuilt)
  • type:B-B road switcher
  • built:Mar 1967, EMD #32878
  • series:1221 produced 1965-71
  • engine:EMD 645E3 (16 cyl, 3000 hp)
  • notes:
  • blt Illinois Central #3058
    to Kansas City Southern #794
    to Helm Leasing #3876
    to New Orleans & Gulf Coast #3876
  • builder

    Shared Motive Power

    Like many national shortline holding companies, Rio Grande Pacific sometimes moves motive power around among its four shortline operations, such as these Wichita Tillman & Jackson Railway locomotives assigned to sister railroad New Orleans & Gulf Coast.

    Wichita Tillman & Jackson #912

  • builder:Electro Motive Division
  • model:GP38-3 (rebuilt)
  • type:B-B road switcher
  • built:Oct 1967, EMD #33345
  • series:706 produced 1966-71
  • engine:EMD 645 (16 cyl, 2000 hp)
  • notes:
  • blt Baltimore & Ohio #3827 (GP38)
    to CSX Transportation #2027
    to Union Pacific #? (GP38-3)
    to Helm Leasing #912
    to Wichita Tillman & Jackson #912
  • builder

    Wichita Tillman & Jackson #914

  • builder:Electro Motive Division
  • model:GP38-3 (rebuilt)
  • type:B-B road switcher
  • built:Oct 1967, EMD #36690
  • series:706 produced 1966-71
  • engine:EMD 645 (16 cyl, 2000 hp)
  • notes:
  • blt Baltimore & Ohio #4814 (GP38)
    to CSX Transportation #2114
    to Union Pacific #2414 (GP38-3)
    to Helm Leasing #914
    to Wichita Tillman & Jackson #914
  • builder

    Locationstag_locations

    tag_pinHarvey

    nogc_logo

    tag_pin

    Click to see the Harvey yard office area plotted on a Google Maps page

    tag_pinGretna

    tag_quote

    Old Gretna (Mechanikham-Gretna Historic District)

    gretna_seal Mechanikham was established in 1836 when wealthy landowner, Nicholas Noel Destrehan,
hired surveyor Benjamin Buisson to divide his long and narrow swath of land on the river into
lots. Buisson’s original symmetrical plan created a two-block-wide settlement with Huey P. Long Avenue (originally Copernicus Avenue) at the center and one street on either side (now Newton and Weyer Streets). Mechanikham quickly became home to many German immigrants who played a vital role in the City’s development and whose descendants became some of Gretna’s most prominent citizens.

    The community of Gretna was established two years later when the St. Mary’s Market Steam Ferry Company purchased and divided a four-block-wide stretch immediately downriver from Mechanikham. Gretna’s streets were regularly laid in the same manner as Mechanikham, and its cross streets were numbered as they are today. An essential feature of the new development was its dedicated ferry landing located directly across the river from St. Mary’s Market in New Orleans.

    City of Gretna

    tag_pin

    Click to see the Southern Pacific depot plotted on a Google Maps page

    morgans_banner1910

    tag_closeup Illinois Central #9559

    tag_pin

    Click to see the Texas & Pacific depot plotted on a Google Maps page

    tp_banner1910

    tag_pinGouldsboro

    On the side of the large 9-track Gouldsboro yard that is opposite the Mississippi River, the south side, the 24-mile branchline downriver to Belle Chase and Myrtle Grove diverges from the Westwego-Algiers line via a trailing point switch. Larger trains leaving the first line for the second often make use of two sets of motive power, one set on each end, to change directions for the trip down river. The eastern end of the yard passes underneath the twin spans of the Crescent City Connection highway bridge over the Mississippi River.

    gouldsboro_guide1910

    1910 Texas & Pacific timetable / collection

    tag_pin

    Click to see this location plotted on a Google Maps page

    Action

    chase_signRoute 18 chase

    chase1a chase1b chase1c

    Marrero, La / Jul 2019 / RWH

    tag_pin

    Click to see this location plotted on a Google Maps page

    chase11a chase11b chase11c chase11d

    Marrero, La / Jul 2019 / RWH

    tag_pin

    Click to see this location plotted on a Google Maps page

    tag_pin

    Click to see the Harvey Canal bridge area plotted on a Google Maps page

    tag_pin

    Click to see this location plotted on a Google Maps page

    chase24a chase24b chase24c chase24d

    Harvey, La / Jul 2019 / RWH

    chase28a chase28b chase28c

    Gretna, La / Jul 2019 / RWH

    tag_pin

    Click to see 4th Street trackage plotted on a Google Maps page

    chase30a chase30b chase30c chase30d chase30e chase30f

    Gretna, La / Jul 2019 / RWH

    chase31a chase31b chase31c

    Gretna, La / Jul 2019 / RWH

    tag_pin

    Click to see this crossing plotted on a Google Maps page

    tag_pin

    Click to see this location plotted on a Google Maps page

    chase40a chase40b chase40c chase40d

    Gretna, La / Jul 2019 / RWH

    chase41 chase42 chase43 chase44

    Gretna, La / Jul 2019 / RWH

    chase_signMadison Street chase

    tag_pin

    Click to see this location plotted on a Google Maps page

    chase46a chase46b chase46c

    Gretna, La / Jul 2019 / RWH

    chase49a chase49b chase49c chase49d

    Gretna, La / Jul 2019 / RWH

    tag_pin

    Click to see this location plotted on a Google Maps page

    chase52a chase52b chase52c

    Gretna, La / Jul 2019 / RWH

    tag_pin

    Click to see this location plotted on a Google Maps page

    chase69a chase69b chase69c chase69d

    Gretna, La / Jul 2019 / RWH

    tag_lagnLagniappe
